Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
7 15A Trailer tow stop/turn lamps
8 15A Ignition switch power, PATS
9 2A 6-speed transmission/PCM
(Ignition RUN/START), Fuel
pump relay
10 5A Front wiper RUN/ACC (relay in
PDB)
11 5A Radio start
12 5A RUN accessory – Radio, Trailer
tow battery charge (relay in PDB)
13 15A Spare
14 20A Horn
15 10A Reverse lamps
16 10A Trailer tow reverse lamps
17 10A RUN/START – RCM (restraints),
PAD lamp, OCS module
18 10A RUN/START – IVD switch, IVD,
4x4 module, 4x4 switch, Heated
seat switches, Compass,
Electrochromatic mirror, RSS
module
19 — Not used
20 10A RUN/START – Manual climate
control, DEATC, Brake shift
21 — Not used
22 15A Brake switch, Stop lamps, Turn
lamps
23 15A Interior lamps, Puddle lamps,
Cargo lamp, Battery saver,
Instrument illumination
24 10A Instrument cluster, Theft LED
