4x4 w/automatic transmission
Engine Rear
axle
ratio
Maximum
GCWR - lb
(kg)
Maximum
trailer
weight - lb
(kg)
Maximum frontal
area of trailer - ft 2
(m 2 )
Regular Cab w/6’ box
4.0L All 9500 (4309) 5740 (2603) 50 (4.64)
Regular Cab w/7’ box
4.0L All 9500 (4309) 5680 (2576) 50 (4.64)
SuperCab
4.0L All 9500 (4309) 5600 (2540) 50 (4.64)
For high altitude operation, reduce GCW by 2% per 1,000 ft.
(300 meters) of elevation.
For definition of terms used in this table, see Vehicle loading earlier in
this chapter.
To determine maximum trailer weight designed for your vehicle, see
Calculating the load your vehicle can carry/tow earlier in this
chapter.
Maximum trailer weight is shown. The combined weight of the
completed towing vehicle (including hitch, passengers and cargo) and
the loaded trailer must not exceed the Gross Combined Weight Rating
(GCWR).
The Ranger is capable of pulling the maximum trailer weight(s) as
specified above. Certain states require electric trailer brakes for trailers
over a specified weight. The Ranger vehicle electrical system is not
equipped to accommodate electric trailer brakes.
WARNING: Do not exceed the GVWR or the GAWR specified on
the certification label.
WARNING: Towing trailers beyond the maximum recommended
gross trailer weight exceeds the limit of the vehicle and could
result in engine damage, transmission damage, structural damage, loss
of vehicle control, vehicle rollover and personal injury.
Preparing to tow
Use the proper equipment for towing a trailer and make sure it is
properly attached to your vehicle. Contact your authorized dealer or a
reliable trailer dealer as soon as possible if you require assistance.
