Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
9 40A* Anti-lock Brake System
(ABS)/AdvanceTrac pump
10 30A* Starter
11 30A* Powertrain Control Module (PCM)
relay
12 20A* ABS/AdvanceTrac valve
13 20A** Left HID
14 10A** Brake on/off (BOO) switch
15 15A** Refrigerator
16 20A** Right HID
17 10A** Alternator
18 20A* Rear quarter panel power point
19 20A* Power point (front console)
20 40A* Rear defroster
21 20A* Rear console power point
22 20A* Sub woofer amp
23 7.5A** PCM Keep alive power, Canister
vent
24 10A** A/C clutch relay
25 25A** Rear wiper
26 20A** Backup relay
27 15A** Fuel relay (Fuel pump driver
module, Fuel pump)
28 80A* Cooling fan
29 30A* E-brake (trailer tow)
30 40A* Battery charge (trailer tow)
31 30A* Auxiliary blower relay
32 30A* Driver seat motors, Memory
module
33 — Not used
34 30A* Power liftgate
35 40A* Front A/C blower motor
