Page 257
SuperCrew 4x4 (145” wheelbase) Harley-Davidson
Engine
Rear axle ratio
Maximum
GCWR - lb
(kg)
Maximum
trailer weight -
lb (kg)
5.4L
3.73
11200 (5080)
5100 (2313)
SuperCrew 4x2 (157” wheelbase)
Engine
Rear axle ratio
Maximum
GCWR - lb
(kg)
Maximum
trailer weight -
lb (kg)
4.6L 2V
3.55
10600 (4808)
5100 (2313)
3.73
11100 (5035)
5600 (2540)
4.6L 3V
3.31
13500 (6123)
8000 (3629)
3.55
14900 (6759)
9300 (4218)
5.4L
3.15
14000 (6350)
8400 (3810)
3.55
15300 (6940)
9700 (4400)
3.73
17000 (7711)
11300 (5126)
SuperCrew 4x4 (157” wheelbase)
Engine
Rear axle ratio
Maximum
GCWR - lb
(kg)
Maximum
trailer weight -
lb (kg)
4.6L 3V
3.55
13500 (6123)
7600 (3448)
3.73
15100 (6849)
9200 (4173)
5.4L
3.31
14000 (6350)
8000 (3629)
3.55
15500 (7031)
9500 (4309)
3.73
15500 (7031)
17100 (7756)*
9500 (4309)
11100 (5035)*
*Maximum GCWR and trailer weight when equipped with Max Trailer
Tow package.
Trailer frontal area considerations:
• Not to exceed towing vehicle frontal area 36 ft
2
(3.4 m
2
) without the
Class IV trailer towing package.
• Not to exceed 45 ft
2
(4.18 m
2
) with the Class IV trailer towing
package for vehicles with 3.15 rear axle ratio only.
• Not to exceed 60 ft
2
(5.52 m
2
) with the Class IV trailer towing
package - excluding vehicles with 3.15 rear axle ratio.
