Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
26 20A** Left high intensity discharge
headlamp relay
27 20A** Right high intensity discharge
headlamp relay
28 — Not used
29 30A* Passenger front window
30 — Not used
31 30A* Passenger power seat
32 30A* Driver power seat
33 30A* Front amplifier (Shaker 500
radio)
34 30A* Driver front window motor
35 40A* Convertible top motor
36 Diode Fuel diode
37 — Not used
38 15A** Fuel injectors (Shelby only)
39 5A** Rear defroster coil (run/start)
40 15A** PCM vehicle power 4 – ignition
coil
41 G8VA relay Fuel pump relay
42 G8VA relay Intercooler pump relay (Shelby
only)
43 G8VA relay A/C compressor relay
44 — Not used (spare)
45 5A** PCM run/start
46 5A** PCM vehicle power 3 – general
powertrain components
47 15A** PCM vehicle power 1
48 15A** Mass air flow sensor
49 15A** PCM vehicle power 2 – emissions
related powertrain components
50 Full ISO relay Cooling fan relay (high)
