9
Figure 3-8
Attaching The Blower Chute
(If E
quipped)
NOTE: The bag must be removed before installing the
blower chute.
8. a. Grasp blower chute with one hand and slide locking
rod on mounting bracket with other hand toward
engine. Use the end of mounting bracket as lever-
age when sliding the locking rod. See Figure 3-8.
b. Slip blower chute over rim of discharge opening
and release locking rod to secure chute in place.
c. Raise the nozzle height to the highest setting when
using the blower chute. Refer to nozzle height
adjustment in the MAINTENANCE section in this
manual.
NOTE: The bag/chute switch button attached to the
mounting bracket must be fully depressed by the tip of
front tab on the blower chute or engine will not start.
3
Setting Up
Your Yard
Vacuum
NOTE: The bag must
be removed before
installing the blower
chute.
A
B
