Optional cluster
Shown in standard measure. Metric similar.
1. Multifunction display: This displays the fuel gauge, tachometer,
engine coolant temperature, odometer/trip meter and other vehicle
features. This is also used to configure different vehicle personalization
options and display the status of various vehicle functions. See Uplevel
message center in this chapter for more information.
2. Speedometer: Indicates the current vehicle speed.
3. Infotainment display: This display is used for the entertainment,
phone, navigation and climate systems. See the MyFord Touch
supplement for more information.
1 3 2
km/h
20 0
40
60
80
100
120
140
160
180 200
80
60
40
20
0
100 120
140
MPH
Instrument Cluster
21
