FASS FA F16 150G User Manual
Page 13
F.
Using quick disconnect tools, remove the fuel lines from the front of the factory HFCM lift pump. Re-
move the fuel lines attached to the rear of the factory HFCM lift pump by pressing in on the tabs.
G.
Route the fuel line from the “E” port of the FASS to the factory lift
pump’s outlet quick disconnect and cut to length. Insert the PLB-
1212 into FASS fuel line using oil. Slide the PLB-1212 into the facto-
ry quick disconnect until you hear a click. Lock down factory retainer
clip.
H.
Measure between the two factory return fittings. Insert two PLB-1238 fittings into the provided FL-
1002 fuel line using oil. Insert fuel line into factory quick disconnects until you hear a click. Lock
down retainer clip. Secure fuel line and wire harnesses.
Note: Secure all fuel lines with cable ties. Cable ties are an economical way to prevent the
possibility of problems occurring!
