FASS FA D02 150G User Manual
Page 13
Remove inlet fuel line from the factory filter housing. Pinch in tabs
and pull off factory fitting on the inlet side. Unbolt and remove the
factory lift pump. Use a Big Block Chevy block off plate to seal en-
gine block. Drain filter, blow out fuel lines and cover or plug any
open ends.
H.
Attach PL-2003 to DIPF-1003 on the filter housing. Torque to 18 ft/
lbs.
G.
Cut fuel line and attach PL-2003 90° fitting. Use oil on fitting and
hose.
F.
Disconnect factory fuel line from inlet side of the filter housing and
install the DIPF-1003 fuel fitting. Torque to 18 ft/lbs. The factory
fuel line can be discarded. See note at bottom of page.
Note: Secure all fuel lines with cable ties. Cable ties are an economical way to prevent the
possibility of problems occurring!
