EcoPure MW_MW40_450216A - Manual (Page 29)

...........................................................................
AUTOMATIC WATER SOFTENER
REPAIR PARTS
KEY
NO.
PART
NUMBER
DESCRIPTION OF PART
1 7131755 Screw, #6–20 x 7/8 (2 req.)
2 7133008 Motor (incl. 2 ea. of Key No. 50)
3 7218816 Motor Plate
4 0900857 Screw, #6–20 x 3/8 (3 req.)
5 7171250 Bearing
6 7219545 Cam and Gear
7 7169180 Clip (Drain)
8 0900431 Hose Clamp
9 7250347 Drain Line Adaptor
- 7139999 Drain Tubing (not shown)
10 7172793 Drain Hose Adaptor
11 7170288 O-ring, 15/16 x 1-3/16
12 7178171 Flow Plug
13 - O–ring, 5/8 x 13/16
14 - O–ring, 1-1/8 x 1-1/2
15 7174313 Bearing, Wave Washer
16 7185500 Rotor & Disc
17 - O–ring, 4-1/2 x 4-7/8
18 - Rotor Seal
19 - Seal
20 7171187 Plug (Drain Seal)
21 7129889 Spring
22 7089306 Clip
(2 req.)
23 7077642 Copper Tube, 1” (2 req.)
24 7170262 O-ring, 1-1/8 x 1-3/8 (4 req.)
25 7094898 Turbine Support
26 7101548 Turbine
27
7248722 Sensor Housing / Wiring Asm
28 0900060 O-ring
29
7081201 Retainer (Nozzle & Venturi)
30 - Seal (Nozzle & Venturi)
KEY
NO.
PART
NUMBER
DESCRIPTION OF PART
31 7171145 Valve Body
32 7170319 O-ring, ¼ x 3/8 (2 req.)
- 7253808 Nozzle & Venturi Asm. (inc. Key Nos.
33, and 35 through 42)
33 7081104 Housing, Nozzle & Venturi
34 1202600 Nut - Ferrule
35 7095030 Cone Screen
36 1148800 Flow Plug, .3 gpm
37 7114533 Nozzle and Venturi — Gasket Kit
- 7204362 Gasket (only)
38 7084607 Flow Plug
39 7146043 Screen
40 7167659 Screen
Support
41 7170262 O–ring, 1-1/8 x 1–3/8
42 7199729 Cap
43 7175199 Wave
Washer
44 7171161 Valve Cover
45 7172997 Screw, #10 x 2-5/8 (8 req.)
46 7145186 Switch
47
7140738 Screw, #4–24 x 3/4 (2 req.)
48 7214383 Bypass Valve (Includes following parts)
- 7172882 Stem
- 7173016 O-ring, 1.109 I.D. x 1.387 O.D. (4)
- 7175238 C-ring
7185487 Seal Kit (incl. Key Nos. 13, 14, 17, 18,
19 and 30)
29
