6
Programming Instructions
Important: The MTH-103E must first be programmed prior to operation.
When initially powering up the unit, the display will first indicate the firmware version and then
go to the operational mode.
To configure each input, first go to the main programming screen by pressing the Menu /
Escape key:
Note: If a screen is displayed showing a keypad, this indicates that a security code has been
enabled. Please see “System Settings” section on page 7 for the description of setting a
security code.
The main configuration screen shows the following icons:
Gear Teeth Settings - for selecting number of gear teeth
Hourmeter Settings - configures hourmeter count up or count down
Alarm Settings - for enabling low / high alarms
Alarm Logs - for accessing alarm log info
System Settings - for selecting default display
Configuration of “Gear Teeth Settings”
Using the arrows on the keypad, select the “Gear Teeth Settings” icon and press enter.
Here, you will need to set the number of gear teeth for proper RPM display. The MTH-103E
will allow any number from 1 to 360 teeth.
Always use the right arrow key for selecting and advancing to the next screen.
