Introduction
Thank you for choosing IMClean! This Quick Start Guide covers the
initial setup of your device.
Your IMclean Kit includes:
• IMClean
• Driver CD
• Vehicle Cable
• USB cable
• Self Test Cable
• Cigarette Lighter Adaptor Cable.
• External power cable w/Battery clamps
• Bluetooth dongle(only with Bluetooth units)
The vehicle cable is custom made by Drew Technologies, Inc. To
obtain replacement/additional vehicle cables, please contact Drew
Technologies, Inc. Generic vehicles cables, or cables provided from
other tools/devices will not
function with the IMClean interface.
DAD Device, CD, and Bluetooth
dongle
Cables included
DAD Indicator Lights
PC Cable Vehicle Protocol Test
Green = USB
active
Blue = Bluetooth
active
Red = no drivers
installed
Green = ok
Red = no cable
connected or
improper cable
connected
Green = vehicle
connected
No indication =
voltage less than
8V on OBD port.
Try external cable
Green flashing =
communicating
with vehicle
Green solid =
connected to
vehicle
Green = self test
is active
Red = test failed
