Description of transmitter parts – Dogtra 210 Series User Manual
Page 5
6
TRANSMITTER
Transmitter Antenna
A short 2 antenna is supplied with the
transmitter.
The antenna should be screwed into the top of
the transmitter to ensure that the signals are sent
properly to the collar receiver and that maximum
range is attained.
2 Antenna
7
TRANSMITTER
DESCRIPTION OF
TRANSMITTER PARTS
transmitter
Antenna
Indicator Light
“Nick” Button
“Pager” Button
“Constant” Button
Intensity
Selection Dial
Selector or Toggle
Switch
indicates optional switch for 2-dog models
