Typical Triaxial Sample Prep Items
Part #
Qty
Description
HM-4180.XX
1
Membranes, 12/pk
HM-4181.XX
1
Membrane Stretcher
HM-4182.XX
1
O-Rings, 12/pk
HM-4184.XX
2
Porous Stone
HM-4187E
1
De-Airing Tank, 6 Liter, 110V
HM-3847.XX
1
Split Miter Box
HM-4189.XX
1
Filter Paper, 100/pk
HM-4189FS
1
Filter Strips 5 x 150mm 100/pk
Part Numbers ending in .XX require a size code to be entered referring to
the sample size to be tested. For Triaxial samples, sizes are: .14 = 1.4";
.15 = 1.5"; .20 = 2.0"; .25 = 2.5"; .28 = 28"; .30 = 3.0".40 = 4.0";
.35 = 35mm; .38 = 38mm; .50 = 50mm; .70 = 70mm, and .100 = 100mm.
Typical Soil Cement Setup using HM-2800
Part #
Qty
Description
HM-2800
1
Multi-Speed Load Frame
HM-2003E
1
Upper Swivel Platen
HM-4454.050
1
Load Ring 5,000 lbf (25 kN)
