Maytag GEMINI - Manual (Page 20)

©2000 Maytag Appliances Sales Company
16010107 Section 3. Component Description 3-10
LOWER DOOR
To Replace Lock Assembly
1. Disconnect the appliance from power
source before servicing.
2. Open oven door or remove for
convenience.
3. Remove main top and slide forward.
Disconnect wire harness. (See Top
Removal).
4. Lift top off and lay aside securely.
5. Remove two (2) screws securing lock
assembly to oven frame in front.
6. Disconnect wiring.
7. Remove two (2) screws securing lock
assembly to frame.
8. Slide assembly out.
9. Reverse procedure to reinstall.
Lower Latch Assembly
1. Disconnect the appliance from power
source before servicing.
2. Remove main top assembly as described
previously and lay aside securely.
