Calyx FEMTI 125 / Triple Mode Amplifier - Manual (Page 10)

10
B : Bridged Mono Mode
Caution
Turn off the power to all components before making connections.
In this mode, the Calyx FEMTI Amplifier be used as a monaural amplifier or multi-channel
amplifier in 5 or 7 channel applications.
Connect your preamplifier using RCA cable.
Input connection is located on the rear left labeled ‘
’ or ‘L’
Select the Output Mode Selector switch located on the rear to ‘B’
Loudspeaker connection should be connected to the
BRIDGED + and BRIDGED . Make sure to
connect the + and + and – and – between the amplifier and speaker.
After ensuring all connection, turn the Calyx FEMTI Amplifier power on and violet LED light will
turn on. After 5 seconds, the amplifier will stabilize and switch to normal operation mode.
Pre-amplifier
Right Speaker Left Speaker
Calyx FEMTI Amplifier Calyx FEMTI Amplifier
