8
6 Digital Inputs
The digital signal can be used using various types of cables.
AES-EBU 1, 2 ----------110 Ohm digital cables. The connectors look same as XLR connectors.
Coaxial 1, 2
-------------75 Ohm coaxial cables
Optical 1, 2
------------Optical fiber cables
BNC --------------------- 75 Ohm coaxial cable
USB ----------------------USB 2.0 compliant cable
7 Analog Outputs
Connect one of the analog outputs to the input of your pre-amplifier or power amplifier
Unbalanced (or RCA) outputs
These connectors accept standard unbalanced cables with RCA-type plugs.
Balanced outputs
These are balanced connectors which ensure superior signal transmission.
The pin assignment is as followings:
Pin 1: Ground
Pin 2: Non-inverted (or Hot)
Pin 3: Inverted (or Cold)
8 AC-Inlet
Insert the supplied power cord into this connector and plug the other end into a wall AC
outlet.
WARNING
 Do not use the unit with any other than the supplied power cords.
 The shape of the AC inlet and the plug of the supplied power cord depend on the
voltage rating and destination country. Using any other type of cable except the
supplied power cord poses the risk of fire and damage.
 This product is available in version for 100V, 110~120V, or 210~230V AC. Make sure
that the voltage shown on the rear panel matches the AC line voltage in your area.
CAUTION
Please check the output level as “0” when you connect FEMTO
to your amplifier directly.
