Craftsman TRACTOR LIFT 610.246 - Manual (Page 10)

30 8
Tube Handle
Snap Button
Turn 180
Figure 1 Figure 2
Snap Button
Step 3. Engaging Stabilizer Bar
Stabilizer bar MUST be engaged immediately after raising the tractor.
WARNING: Failure to engage stabilizer bar may result in serious personal
injury and or property damage.
Remove ring grip pin ( 30 ) from tube handle. Press snap button •
and slide stabilizer bar ( 8 ) from foot bar tube.
Turn stabilizer bar 180 degrees as shown at bottom of Figure 1. •
Position stabilizer bar under base of unit between wheels. •
Slide stabilizer bar back onto foot bar tube making sure the bar is •
positioned back over snap button.
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m. E.S.T.
Page 10.
OPERATION
Using the Tractor Lift
