Head Section Articulation
WARNING:
Surface positions that cause the patient’s torso to be at an angle less than 90°
to the legs could reduce circulatory efficiency in the lower extremities. Such
positions are not recommended for extended periods of time and should be
under medical supervision. Patient injury could occur.
WARNING:
Make sure to fully control the lift mechanism when there is little or no weight
on it. Failure to do so could cause it to rise quickly and cause injury or equipment damage.
To raise the Head Section:
Squeeze the bar under the head section and lift up on the head section.
Release the bar when the desired position is reached. The head section locks in place.
To lower the Head Section:
Squeeze the bar under the head section and push down on the head section.
Release the bar when the desired position is reached. The head section locks in place.
Knee Surface Articulation Crank
To raise the Knee Surface:
a. Pull out the crank handle from its stored position under the
foot section.
b. Turn the crank handle clockwise until the knee surface reaches the
desired position.
To lower the Knee Surface:
c. Pull out the crank handle from its stored position under the foot section.
d. Turn the crank handle counterclockwise until the knee surface reaches the desired position.
After raising or lowering the knee surface, return the crank to its stored position.
