Installation – Amico Majestic Series Single Tier Surface Mounted Headwall User Manual
Page 3
www.amico.com
3
Installation
1. Using shop drawings, mark both devices center line AFF (above finished floor) on wall.
2. Mark horizontal line for bottom of mounting bracket (to be installed later). This line is to be off-
set 4" (102 mm) above devices center line.
devices center line AFF
Unit shown for reference only
Note
4
devices center line AFF
bottom of mounting
bracket line AFF
