Great Plains Mfg., Inc.
Installation Instructions 5
10/09/2006 168-045M
Connect New Sensor Cable (all Screens)
16. Determine desired cable routing.
17. Trim excess overlap length from existing cable. Allow
enough length for wire-stripping.
18. Strip 3 ⁄ 8 -inch from each old wire.
Crimp on a connector.
19. Attach the new connectors to the new sensor’s cable
connectors.
Note: The sensor is a switch and the circuit is not polar-
ized.
20. Protect the connection with electrical tape.
Parts List
168-044A Fan Sensor Kit
Your kit includes:
Qty. Part No. Part Description
1 168-045M This manual
1 168-073D FAN SENSOR MOUNT
1 823-250C COIL PICKUP SENSOR
