79 Single Press
Operating Instructions
7. Parts and Assembly
AS3891 4.2m RH WING DD700 WING
LAYOUT
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS1208 AXLE ASSEMBLY - DD700 9 RINGS 1
2 P02008 NUT LOCK M16 'TYPE T' 12
3 P02602 WASHER FLAT M16 12
4 P04179 WASHER FLAT M12 Ø38 16
5 P06802 BOLT U M16 GR8.8 190x117 6
6 P08923 DECAL - DD SMALL 1
7 P09558 SCRAPER PLATE 6
8 P09559 SCRAPER STEM RH 4
9 P09560 SCRAPER STEM LH 2
10 P10029 SCRAPER 1 1/2 2
11 P10870 BOLT M12x30 GR. 8.8 16
12 P11694 DECAL - GREASE 10 HOURS 2
13 P12558 DECAL - AXLE TENSION 1
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
