Page 159
159
Single Press
Operating Instructions
7. Parts and Assembly
AS4444
SINGLEPRESS 6.6, 7.6 & 8.2 -
WING FOLD HYDRAULICS
ITEM
PART NO
DESCRIPTION
QTY
COMMENTS
1
P00166
CYLINDER - Ø75x400
4
2
P00181
HA 1/2"X2135
1
3
P00183
HA 1/2"X2743
1
4
P00200
BANJO BLOCK ½" BSP
8
5
P00201
BANJO BOLT ½" BSP
6
6
P00203
ADAPTOR MALE-MALE ½" BSP
8
7
P00204
ADAPTOR T ½" BSP
1
8
P00205
QUICK RELEASE MALE - ½" BSP
2
9
P00206
ADAPTOR MALE-FEM ½" BSP
2
10
P00724
BANJO BOLT ½" BSP RESTRICTED
2
11
P02263
DOWTY SEAL ½" BSP
29
12
P02734
ELBOW MALE-FEM COMPACT ½" BSP
2
13
P02735
BULKHEAD ½" BSP
4
14
P03686
ADAPTOR MALE - MALE ½"-3/8" BSP
11
15
P03687
DOWTY SEAL 3/8" BSP
20
16
P05162
ELBOW MALE-FEM 45° SWEPT ½" BSP
2
17
P06217
ADAPTOR T SFOE ½" BSP
5
18
P06720
CHECK VALVE 1/2"BSP - 5 BAR
1
19
P06728
55 BAR RELIEF VALVE
1
20
P07930
DOC VALVE VODL/SC12
1
21
P07977
BLANKING PLUG 3/8" BSP
9
22
P08097
0.7L ACCUMULATOR 150BAR
2
23
P08700
HA 1/2"X470
1
24
P09112
CLAMP ½" BSP PAIR
1
25
P09113
CLAMP - TOP PLATE
1
26
P09537
CAP FOR MALE - YELLOW
2
27
P09968
HA 1/2"X1020
1
28
P09970
HA 1/2"X820
1
29
P10278
BOLT M8x45 GR. 8.8
1
30
P10327
HA 1/2"X560 SW90°
1
31
P14090
CONNECTOR BLOCK 3/8" BSP
2
32
P18769
HA 1/2"X2135
1
33
P18770
HA 1/2"X2743
1
34
P18772
HA 1/2"X820
1
35
P18773
HA 1/2"X820
1
36
P18774
HA 1/2"X1020
1
37
P18775
HA 1/2"X1020
1
38
P18776
HA 1/2"X1020
1
39
P18777
HA 1/2"X560 SW90°
1
40
P18778
HA 1/2"X250
1
41
P18779
HA 1/2"X250
1
42
P18780
HA 1/2"X820
1
43
P18781
HA 1/2"X715
1
44
P18782
HA 1/2"X715
1
45
46
47
48
49
50
