AS4556 DDL ROLL FRAME ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 604-003H SCRAPER RAIL-3.5M 1
2 604-004H ROLL FRAME-DTX350 1
3 604-010D PILLAR-FLANGE FITTING 2
4 AS4150 SCRAPER ASSEMBLY DDL200 17
5 P01834 BEARING SCJ 50 2
6 P02007 NUT LOCK M12 8
7 P02008 NUT LOCK M16 'TYPE T' 6
8 P02601 WASHER FLAT M12 8
9 P02602 WASHER FLAT M16 6
10 P03066 BOLT M20x40 GR10.9 CSK 8
11 P05030 SCREW M12x55 CSK GR10.9 16
12 P06802 BOLT U M16 GR8.8 190x117 3
13 P12758 STUB AXLE END WASHER Ø50 2
14 P12950 BOLT M12x35 SOCKET CAP 4
15 P13377 RETAINING PLATE 2
16 P15186 DD600 RING - 275 BORE 34
17 P16530 DDL 600 SPACER 107MM 17
18 P16707 INTRNL SPACER 86X8M 17
19 P18102 ROLL TUBE - 3500mm 1
