7. Parts & Assembly
AS2945 H YD R AU LIC CIR CU IT - FOLD
IT EM PART NO DESCRIPTION QT Y COMMENT S
1 AS1717 WING CYL ASSEMBLY 6
2 P00202 ADAPTOR FEM - FEM ½" BSP 1
3 P00203 ADAPTOR MALE-MALE ½" BSP 26
4 P00204 ADAPTOR T ½" BSP 4
5 P00205 QUICK RELEASE MALE - ½" BSP 2
6 P00209 ADAPTOR 4 WAY ½" BSP 1
7 P00774 SHUT OFF TAP ½" BSP 2
8 P01796 M3/8"-F1/2" 1
9 P02263 DOWTY SEAL ½" BSP 31
10 P02730 QUICK RELEASE FEM. ½" BSP 2
11 P02734 ELBOW MALE-FEM COMPACT ½" BSP 2
12 P02735 BULKHEAD ½" BSP 8
13 P03686 ADAPTOR MALE - MALE ½"-3/8" BSP 2
14 P03687 DOWTY SEAL 3/8" BSP 3
15 P04529 RELIEF VALVE 250BAR 1
16 P06216 ADAPTOR T SFOR ½" BSP 5
17 P06217 ADAPTOR T SFOE ½" BSP 2
18 P07930 DOC VALVE VODL/SC12 1
19 P08837 ACCUMULATOR 2L PISTON 80b 2
20 P09112 CLAMP ½" BSP PAIR 4
21 P09113 CLAMP - TOP PLATE 1
22 P09422 VALVE FDC VDFR38-24 3/8" 1
23 P09967 CROSSLINE RELIEF VALVE 1
24 P10049 BOLT M8x25 STAUFF STACK 3
25 P10096 BOLT M8x35 GR. 8.8 1
26 P10234 LOCK CLIP 3
27 P16057 HK-1/2"X1850MM 1
28 P16058 HA-1/2"X2850MM 1
29 P16062 HA-1/2"X700MM 1
30 P16063 HK-1/2"X960MM 1
31 P16064 HK-1/2"X1240MM 2
32 P16065 HK-1/2"X400MM 1
33 P16066 HK-1/2"X550MM 1
34 P16067 HK-1/2"X1070MM 1
35 P16068 HK-1/2"X1150MM 1
36 P16069 HK-1/2"X1070MM 1
37 P16071 HK-1/2"X1140MM 1
38 P16072 HK-1/2"X1100MM 1
39 P16081 HK-1/2"X960MM 2
40 P16082 HK-1/2"X1850MM 1
41 P16083 HK-1/2"X1140MM 1
42 P16085 HA-1/2"X700MM 1
43 P16086 HA-1/2"X2600MM 1
44 P16087 HA-1/2"X2600MM 1
45 P16088 HK-1/2"X260MM 2
46 P16089 HK-1/2"X260MM 2
47 P16090 HK-1/2"X2270MM 1
48 P16091 HK-1/2"X2390MM 1
49 P16092 HK-1/2"X5800MM 1
50 P16093 HK-1/2"X5750MM 1
51 P16098 HK-1/2"X1140MM 1
52 P16103 HK-1/2"X960MM 1
53 P16104 HK-1/2"X1240MM 1
54 P16106 HA-1/2"X700MM 1
55 P16107 HK-1/2"X960MM 1
56 P16109 HA-1/2"X700MM 1
57 P16110 HA-1/2"X2850MM 1
