7. Parts & Assembly
AS2470 WING RH C/W TINE FRAME
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2457 TINE FRAME LINK 5
2 AS2458 TINE FRAME RH ASSEMBLY 1
3 AS2518 DISC UNIT RH 13
4 AS2519 DISC UNIT LH 13
5 AS2553 TINE FRAME LINK WITH TRIGER 1
6 AS2923 FRONT WHEEL RIGHT HAND 1
7 H00170108 SPRING Ø4 L 149 2
8 P00015 BOLT M24x75 GR. 8.8 1
9 P00071 NIPPLE - GREASE 7
10 P00407 BOLT M20x80 GR. 8.8 4
11 P01226 PIN Ø25x100 1
12 P01901 BOLT M16x80 GR. 8.8 82
13 P02007 NUT LOCK M12 9
14 P02008 NUT LOCK M16 86
15 P02009 NUT LOCK M20 4
16 P02010 NUT LOCK M24 3
17 P02483 LYNCH PIN CAT 1 1
18 P02484 LYNCH PIN CAT 2 1
19 P02601 WASHER FLAT M12 18
20 P02602 WASHER FLAT M16 168
21 P02603 WASHER FLAT M20 8
22 P02604 WASHER FLAT M24 Ø50 8
23 P02649 BOLT M16x90 GR. 8.8 4
24 P03087 BOLT M12x50 GR. 8.8 7
25 P03117 BOLT M24x120 GR. 8.8 1
26 P07361 GREASE NIPPLE 45° 2
27 P07543 PLASTIC END CAP 40x40 4
28 P07922 BUSH SPRUNG - Ø32xØ26x15 2
29 P08331 WASHER FLAT M24x2 19
30 P08833 SHIM COLLAR Ø45 1
31 P08866 BOLT M12x110 GR8.8 2
32 P09162 TOOLBOX LID 1
33 P10017 TOOLBOX BODY 1
34 P11156 SHIM KIT FOR Ø60mm ROD 1
35 P12610 BOLT M24x120 GR 10.9 STR 1
36 P12620 TOP PLATE 26
37 P12621 SPACER Ø36xØ16.5x31mm 52
38 P12783 LYNCH PIN CAT 0 26
39 P12810 NUT CASTLE M24 26
40 P12815 BOLT M24x185 STRUCTURAL GR 8.8 26
41 P14334 WING RH 1
42 P14405 6.7m TRACKROD 2
43 P14481 GANG ANGLING JACK 2
44 P14629 LATCH 1
45 P15429 TIE BAR JACK MOUNT 2
46 P15434 PIN - ROLL PIVOT 4
47 P15438 ANGLE GUIDE 2
48 P15482 PIN - WING PIVOT 3
