Legend: ➊ = 1st revision; ➋ = 2nd revision; ➌ = 3rd revision; ● = use up existing stock; ⊗ = not interchangeable; ⊗ ➀ ➋ = for example: revision 2 is not interchangeable w/revision 1
599-023P
Ref. Part No. Part Description Comments
4-4 Hydraulics
4
Table of Contents ➧ Part Number Index ➧
Hydraulic Cylinder (810-521C 4x16x1.38 Rod)
1. 1M7016 CLEVIS ROD MIDWAY
2. 2M6824 MW ROD
3. 3R5812 MW HEAD
4. 4R5108 PISTON MIDWAY
5. 5R5124 MW TUBE
6. 6R5164 BASE MIDWAY
7. 7M6324 MW TIE ROD 4 X 16 CYLINDER
8. MW WIPER SEAL Only available in item 22
9. U-CUP Only available in item 22
10. O-RING MIDWAY Only available in item 22
11. BACK UP MIDWAY Only available in item 22
12. TEFLON SEAL Only available in item 22
13. O-RING LOADER MIDWAY Only available in item 22
14. WEAR RING MIDWAY Only available in item 22
15. MW PISTON NUT SEAL Only available in item 22
16. 2A0024 MW PISTON NUT 1-14
17. 2A0018 MW TIE ROD NUT
18. 2A0012 MW NUT
19. 802-023C HHCS 3/8-16X1 3/4 GR5
20. 2A0208 MW CLEVIS PIN
21. 2A0132 MW PIN CLIP
22. 810-151C SEAL KIT MW 4 RPH CYL 4A5103
7/25/2005
