Page 13
Legend:
➊
= 1st revision;
➋
= 2nd revision;
➌
= 3rd revision;
●
= use up existing stock;
⊗
= not interchangeable;
⊗
➀ ➋
= for example: revision 2 is not interchangeable w/revision 1
599-023P
Ref.
Part No.
Part Description
Comments
3-4
Transport
3
➧
➧
1.
599-017H
TONGUE GUAGE WHEEL WLMT
2.
800-058C
GREASE ZERK 1/4-28 X 45-DEG
3.
802-099C
HHCS 1/2-13X3 1/4 GR5
4.
803-019C
NUT LOCK 1/2-13 PLT
5.
815-085C
SPINDLE SGL 1.75X10.72
6.
816-011C
SEAL 2.56X1.625X.438 CR16289
7.
822-018C
BEARING CONE LM-29749
8.
822-019C
BEARING CUP LM-29710
9.
802-104C
BOLT WHEEL 1/2-20X1 90-DEG
10.
815-082C
HUB 6 BOLT 4 5/8 PILOT W/ CUPS
11.
822-020C
BEARING CUP LM-67010
12.
822-021C
BEARING CONE LM-67048
13.
804-055C
WASHER SPINDLE - 7/8
14.
805-016C
PIN COTTER 3/16 X 1 1/4 PLT
15.
803-029C
NUT HEX SLOTTED 7/8-14 PLT
16.
200-001D
HUB GREASE CAP
17.
814-178C
TIRE TITAN 11L-15 X 8 PLY
18.
814-221C
WHEEL 15X8 6 BOLT WHITE
19.
816-035C
VALVE STEM TR415X.625X1 1/4 LG
20.
814-232C
TIRE/WHL 11LX15 8PLY W/TB WHT
21.
815-082C
HUB 6 BOLT 4 5/8 PILOT W/ CUPS
22.
815-079C
HUB AND SPINDLE ASSY 6 BOLT
23.
890-264C
BUSHING 1 3/4 X 1 1/2 X 1 1/2
24.
890-005C
BUSHING CYL 1 1/4 X 1 X 1
7/25/2005
