Introduction
Great Plains welcomes you to our growing family of new
product owners. The Series I Ultra-Till 3030-UT5052
have been designed with care and built by skilled work-
ers using quality materials. Proper setup, maintenance,
and safe operating practices will help you get years of
satisfactory use from the machine.
Models Covered
Description of Unit
The Series I Ultra-Till 3030-UT5052 is a three or five-
section seedbed preparation tillage tool. Working width
ranges from 30 to 52 feet. The implement is designed to
combine discing/slicing, with shallow harrowing in a verti-
cal tillage field operation to smooth, level and incorporate
chemicals in a single pre-plant pass.
Document Family
Using This Manual
This manual will familiarize you with
safety, assembly, operation, adjust-
ments, troubleshooting, and mainte-
nance. Read this manual and follow
the recommendations to help ensure safe and efficient
operation.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
A crucial point of information related to the preceding topic.
Read and follow the directions to remain safe, avoid serious
damage to equipment and ensure desired field results.
Note: Useful information related to the preceding topic.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of:
Up, Back, Left, Down, Front, Right.
UT3030 30-Foot 3-section
UT5036 36-Foot 5-section
UT5042 42-Foot 5-section
UT5052 52-Foot 5-section
Figure 1
UT3030 Ultra-Till
43183
L
R
U
D
F
B
L
R
576-026Q Pre-Delivery Manual
576-026M-A Operator Manual (this document)
576-026P Parts Manual
U
D
F
B
L
R
