4. Adjustment/Operation

1.

Bar Coupler

2.

Parking Stand

3.

Front Discs

4.

Spring Reset Tines

5.

Rear Discs

6.

DD Light Roll

7.

Transport Wheels

8.

Axle Cylinder

9.

Disc Angle Adjustment Jack

10.

Clevis Type Drawbar

4.1 Description

Fig. 4.01: Great Plains Simba SL400

1

2

3

4 5

6

7

8

9

4. Adjustment / Operation

10
