AS4190 TINE FRAME ASSEMBLY LH - 7.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS4175 PROACTIVE TINE ASSEMBLY - SPRING ONLY 12
2 AS4176 TINE ASSEMBLY - STRAIGHT TINE 12
3 P02009 NUT LOCK M20 12
4 P02603 WASHER FLAT M20 12
5 P02655 BOLT M20x240 GR. 8.8 12
6 P04053 CLAMP PLATE 2x122x22 2
7 P09432 RETAINING PLATE 120x120x4 2
8 P12122 TINE FRAME LH -7.6m 1
