Great Plains Simba UniPress Parts Manual - Manual (Page 69)

UniPress
Operating Instructions
102
7. Parts and Assembly
103 UniPress
Operating Instructions
7. Parts and Assembly
AS4189 TINE FRAME ASSEMBLY RH - 7.2m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS4175 PROACTIVE TINE ASSEMBLY - SPRING ONLY 11
2 AS4176 TINE ASSEMBLY - STRAIGHT TINE 11
3 P02009 NUT LOCK M20 12
4 P02603 WASHER FLAT M20 12
5 P02655 BOLT M20x240 GR. 8.8 12
6 P09432 RETAINING PLATE 120x120x4 3
7 P12123 TINE FRAME RH - 7.6m 1
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Parts
69 Simba UniPress
607-114P
2013-01-25
