Great Plains Manufacturing, Inc.
Introduction
7
04/12/2012
566-046Q
Unloading
Be sure the truck is on level ground, preferably concrete.
Centering components:
Be sure and center fork truck or chains (overhead hoist) on compo-
nents so they won’t slide and cause injury.
Unload Smaller Items First
Unloading the Turbo-Chisel is a potentially dangerous
operation.
Reduce risk and complications by first unloading
1.
the gangs and finishing attachments
2.
the misc. boxes
3.
the Turbo-Chisel
(described in the next section)
Unload Turbo-Chisel
4.
Place these components well out of the maneuvering
area needed for unloading the Turbo-Chisel.
5.
Double-check that all chains and tie-down straps
have been released and stowed.
6.
Set parking brake on trailer tractor.
7.
Slowly lift the Turbo-Chisel off trailer bed using two
fork lifts.
8.
Stop lifting about 12” above the bed.
9.
Have the truck driver slowly pull the trailer straight
out from under the Turbo-Chisel.
10. Making sure to keep level from front to back and side
to side, slowly lower the Turbo-Chisel.
11. Lower theTurbo-Chisel down until the shipping
stands are about 12” off ground.
12. Remove shipping stands.
13. Remove tongue jack from field positions and put in
storage position with foot of jack towards ground.
14. Slowly lower Turbo-Chisel until it resting on the cen-
ter transport tires and front tongue jack.
Unpacking Boxes
Note: Position boxes in area that you can maneuver
components up to machine to assembly.
15. Carefully remove banding from boxes.
16. Carefully remove banding from gangs and finishing
reels.
17. Locate and identify all components before assem-
bling.
Assembly and Setup Assistance
To order additional copies of pre-delivery instructions or
operator.s and parts manuals, write to the following
address. Include model numbers in all correspondence.
If you do not understand any part of this manual or have
any assembly or setup questions, assistance is available.
Contact:
Product Support
Great Plains Mfg. Inc., Service Department
PO Box 5060
Salina, KS 67402-5060
(800)255-9215
