57 SL700
Operating Instructions
7. Parts and Assembly
AS4496 SL700 - LH WING ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2457 TINE FRAME LINK 6
2 AS2518 DISC UNIT RH 13
3 AS2519 DISC UNIT LH 13
4 AS2924 FRONT WHEEL LEFT HAND 1
5 AS4405 TINE FRAME LH ASSEMBLY 1
6 P00015 BOLT M24x75 GR. 8.8 1
7 P00071 NIPPLE - GREASE 7
8 P00407 BOLT M20x80 GR. 8.8 4
9 P01901 BOLT M16x80 GR. 8.8 74
10 P02007 NUT LOCK M12 6
11 P02008 NUT LOCK M16 'TYPE T' 78
12 P02009 NUT LOCK M20 4
13 P02010 NUT LOCK M24 4
14 P02483 LYNCH PIN CAT 1 1
15 P02601 WASHER FLAT M12 12
16 P02602 WASHER FLAT M16 152
17 P02603 WASHER FLAT M20 8
18 P02604 WASHER FLAT M24 Ø50 6
19 P02649 BOLT M16x90 GR. 8.8 4
20 P03087 BOLT M12x50 GR. 8.8 4
21 P04754 NUT LOCK M8 2
22 P05491 BOLT 1" UNFx4½"" GR. V 1
23 P05492 NUT LOCK 1" UNF 1
24 P05535 WASHER FLAT M8 3
25 P07361 GREASE NIPPLE 45° 2
26 P07543 PLASTIC END CAP 40x40 4
27 P07922 BUSH SPRUNG - Ø32xØ26x15 2
28 P08331 WASHER FLAT M24x2 30
29 P08802 SHIM KIT 7 PIECE 1
30 P08817 WASHER SPRING M8 3
31 P08833 SHIM COLLAR Ø45 1
32 P08866 BOLT M12x110 GR8.8 2
33 P09162 TOOLBOX LID 1
34 P09597 BOLT M8x25 GR. 8.8 3
35 P10017 TOOLBOX BODY 1
36 P11156 SHIM KIT FOR Ø60mm ROD 1
37 P12358 CAPSCREW M8x60 GR10.9 2
38 P12610 BOLT M24x120 GR 10.9 STR 1
39 P12620 TOP PLATE 26
40 P12621 SPACER Ø36xØ16.5x31mm 28
41 P12783 LYNCH PIN CAT 0 26
42 P12810 NUT CASTLE M24 26
43 P12815 BOLT M24x185 STRUCTURAL GR 8.8 26
44 P14402 WING LH 1
45 P14405 6.7m TRACKROD 2
46 P14481 GANG ANGLING JACK 1
47 P15429 TIE BAR JACK MOUNT 2
48 P15434 PIN - ROLL PIVOT 4
49 P15438 ANGLE GUIDE 2
50 P15933 JACK ADJUSTER 1
51 P16816 BOLT M24x160 GR10.9 2
52 P17815 MANUAL HOLDER - COMPLETE 1
