47 SL700
Operating Instructions
7. Parts and Assembly
AS2517 AXLE CARRIAGE ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00071 NIPPLE - GREASE 2
2 P00789 BOLT M24x180 GR. 8.8 16
3 P02010 NUT LOCK M24 16
4 P02012 NUT LOCK M36 2
5 P02541 WASHER FLAT M36 10
6 P02604 WASHER FLAT M24 Ø50 32
7 P03119 BOLT M36x300 GR 8.8 2
8 P08883LH WHEEL ASSEMBLY - 700x22 TYRE 10 STUD 1
9 P08883RH WHEEL ASSEMBLY - 700x22 TYRE 10 STUD 1
10 P10882 BUSH Ø72xØ60x60 NYLON 4
11 P14463 AXLE MOUNTING 1
12 P14471 AXLE - 10 STUD BRAKED 1
13 P14551 AXLE CLAMP PLATE 8
14 P14781 BUSH SPRUNG - Ø44xØ36x30 4
