TSF660
500-644Q 11/7/2006
14
Specifications and Capacities
Model TSF660
Boom Width 60’
Tank Capacity 650 gallon
Nozzle Spacing 20” or 30”
Number of Nozzles 36 (20” spacing)
25 (30” spacing)
Approx. Empty Weight 6,950 lbs.
Approx. Full Weight (Max) 12,400 lbs.
Working Width 63’
Transport Width 108” with wheels in 135” with wheels out
Transport Height 12’
Length 19’10”
Wheel/Tire Size 13.6 - 38 6PLY
Wheel Spacing 60” - 120”
Tire Inflation Chart
Tire Size Inflation
PSI
13.6 x 38 6 ply Tractor Tread 22
14.9 x 46 10 ply Tractor Tread 36
NOTE: All tires are warranted by the original manufacturer of the tire. Tire warranty information can be found
in the brochures included with your Operator’s and Parts Manuals or online at the manufacturer’s websites.
For service assistance or information, contact your nearest Authorized Farm Tire Retailer.
Manufacturer Website
Titan www.titan-intl.com
Goodyear now: www.titan-intl.com
Firestone www.firestoneag.com
