57 Double Press
Operating Instructions
7. Parts and Assembly
AS4158 CHASSIS HD ASSEMBLY (7.2m-8.2m)
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00047 BOLT M36x240 GR. 8.8 4
2 P00071 NIPPLE - GREASE 2
3 P00389 PIN Ø30x125 2
4 P01054 PIN Ø25x140 2
5 P01055 CYLINDER - Ø5"x400 - 63 1
6 P01274 PIN Ø25x115 4
7 P01281 BOLT M12x100 GR. 8.8 2
8 P01645 BUSH SPRUNG - Ø32xØ26x30 4
9 P01646 BUSH SPRUNG - Ø40xØ32x30 1
10 P01647 BUSH SPRUNG - Ø45xØ36x40 4
11 P01709 NUT STAYTIGHT M16 14
12 P02007 NUT LOCK M12 2
13 P02012 NUT LOCK M36 4
14 P02484 LYNCH PIN CAT 2 8
15 P02541 WASHER FLAT M36 4
16 P02602 WASHER FLAT M16 28
17 P02649 BOLT M16x90 GR. 8.8 14
18 P02789 BOLT M8x20 GR. 8.8 8
19 P03788 WHEEL ASSEMBLY - 500/50 2
20 P04233 SPANNER - M60 2
21 P04754 NUT LOCK M8 12
22 P05122 SERIAL PLATE 1
23 P05361 RATCHET STRAP 1
24 P05400 WASHER FLAT M6 3
25 P05535 WASHER FLAT M8 8
26 P07543 PLASTIC END CAP 40x40 2
27 P07546 PLASTIC END CAP 80x80 2
28 P08918 SHIM COLLAR 2 1/2" ROD 1
29 P10293 BOLT M6x20 GR. 8.8 3
30 P11689 BOLT M8x110 GR. 8.8 2
31 P12056 DOC + PR RED. MANIFOLD 1
32 P12358 CAPSCREW M8x60 GR10.9 2
33 P14024 BACK PLATE 3
34 P15189 BRAKED AXLE 6 STUD 1
35 P17369 UNIPRESS PARKING STAND 2010 2
36 P17386 CHOCK TYPE UK46St 2
37 P17387 CHOCK CARRIER UK46ST 2
38 P17815 MANUAL HOLDER - COMPLETE 1
39 P17922 CHASSIS HD 1
40 P17954 WHEEL CHOCK MOUNT LH 1
41 P17955 WHEEL CHOCK MOUNT RH 1
42
43
44
45
46
47
48
49
50
