Great Plains P18046B Operator Manual - Manual (Page 41)

41 Double Press
Operating Instructions
7. Parts and Assembly
AS4214 DOUBLE PRESS 4.6m 2011
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS3707 REAR DRAWBAR ASSEMBLY 1
2 AS3709 DRAWBAR ASSEMBLY - 4.6 - 6.6m 1
3 AS3711 LIGHT KIT FRONT 1
4 AS3712 REAR LIGHT BRACKETS 1
5 AS3713 CHASSIS ASSEMBLY - 4.6m - 6.6m 1
6 AS3949 DOUBLE PRESS 4.6m RH WING FRAME AS 1
7 AS3950 DOUBLE PRESS 4.6m LH WING FRAME ASS 1
8 AS3963 TINE FRAME ASSEMBLY 4.6m 2
9 AS3978 DOUBLE PRESS 4.6m STICKER LAYOUT 1
10 P18046 MANUAL - D/PRESS 2011 1
