4/8/99 1-4
175-083M-A
This chart is based on torque requirements in foot pounds for grade 5 bolts.
BOLT MINIMUM MAXIMUM BOLT MINIMUM MAXIMUM
DIAMETER TORQUE TORQUE DIAMETER TORQUE TORQUE
1/4” 9 11 3/4” 270 324
5/16” 17 20 7/8” 400 480
3/8” 35 42 1" 580 696
7/16” 54 64 1 1/8” 800 880
1/2” 80 96 1 1/4” 1120 1240
9/16” 110 132 1 3/8” 1460 1680
5/8” 150 180 1 1/2” 1940 2200
NOTE: Torque requirements listed above do not apply to self-locking nuts. For self-locking nuts increase the torque
requirements listed above by 15%.
NUT & BOLT TORQUING CHART
TIRE INFLATION CHART
TIRE SIZE INFLATION PSI
5.90 x 15" 4 Ply Rib Implement 32
7.50 x 20" 4 Ply Rib Implement 28
9.0 x 22.5 10 Ply Highway Service 70 70
9.0 x 24" 8 Ply Rib Implement 40
9.5L x 15" 6 Ply Rib Implement 32
9.5L x 15" 8 Ply Rib Implement 44
9.5L x 15" 12 Ply Rib Implement 60
11L x 15" 6 Ply Rib Implement 28
11L x 15" 12 Ply Rib Implement 52
12.5L x 15" 8 Ply Rib Implement 36
12.5L x 15" 10 Ply Rib Implement 44
16.5L x 16.1" 10 Ply Rib Implement 36
41 x 15" x 18 22 Ply Rib Implement 44
