Field Operation
This implement is designed to be pulled in the lowered
field position (including wide turns). Lifting for short dis-
tances to clear residue clogs is acceptable. Lifting for
tight turns or reverse moves is required.
Equipment Damage Risk:
Lift for tight turns and reverse moves. Tight turns can result in
a section moving backward. Never back up with harrows on
the ground. If the inside tire stops or rolls backward, the turn is
tight and requires lift.
Field Set-Up Checklists
Use the following tables to develop a final checklist for
your tractor/Turbo Max configuration. Additional or fewer
steps may be necessary depending on tractor features,
Turbo Max options and accessories.
Final Checklist
Mechanical Checklist Page
❑ Turbo Max hitched
15
❑ Hitch pin locked
-
❑ Safety chain secured to tractor or leading
implement
15
❑ Parking jack stowed
15
❑ Check all tire pressures 38
❑ Transport locks and locking valves are in
the field position
18
Hydraulic System Checklist Page
❑ Check tractor hydraulic reservoir full -
❑ Make hydraulic connections
16
❑ Inspect connections for leaks
-
❑ Unfold Implement -
Perform all steps in “Pre-Start Checklist” on page 27
and “Final Checklist” on page 29.
Do not make short radius turns with the implement in the
ground.
Note: If you stop in the middle of a pass, raise the imple-
ment and back up 10’ before resumption of tilling.
Electrical Checklist Page
❑ Verify electrical hookups solid, or connec-
tor securely stowed if not using lights in
field. 16
First Pass Operation Checklist Page
1. Implement unfolded and aligned for first
pass.
-
2. Pull forward, lower Turbo Max, and begin
tilling for a short distance.
-
3. Stop. Assess:
• coulter depth
• finishing attachment operation
-
4. Make necessary adjustments 30
Sharp Field Turns Checklist Page
1. Raise Turbo Max -
2. Make turn -
3. Lower Turbo Max -
4. Resume tilling. -
Ending Tilling Checklist Page
1. Suspend operations as above -
2. Lift implement -
3. Set tractor for fold 18
4. Fold wings -
5. Place locking valves in transport position 18
6. Place transport locks in transport position 18
7. Lower implement on to transport locks -
8. Lights ON for transport -
