Revision
Comments
Part Description
Part No.
Ref.
BRG CONE 1.31IDX1.01WD #2790
822-038C
48.
7/8 SPINDLE WASHER, HARDENED
181-064D
49.
NUT HEX SLOTTED 7/8-14 PLT
803-029C
50.
PIN COTTER 3/16 X 1 1/4 PLT
805-016C
51.
REPLACED BY 890-032C
P502001
52.
Includes 41-52
HUB & SPINDLE ASY 8 BOLT 5790#
815-103C
53.
NUT LUG 5/8-18 X 90 DEG PLT
803-219C
54.
TIRE/WHEEL ASY 15-19.5 LH
814-327C
55.
WHEEL 19.5 X 12.25 8-BOLT
814-324C
56.
VALVE STEM TR415X.625X1 1/4 LG
816-035C
57.
TIRE 15-19.5 NHS 12 PLY
814-325C
58.
HHCS 1-8X1 3/4 GR5 NYL
802-798C
59.
U-BOLT 3/4-10 X 5 1/32 X 4 1/2
806-203C
60.
WASHER LOCK SPRING 3/4 PLT
804-023C
61.
CYL PIN NR 1.25X3.09X2.63 W/GR
196-409H
62.
PIN CLEVIS 1 1/4 X 3 3/8 GR5
805-196C
63.
WASHER HARD 4.0X2.56X10GA
411-338D
64.
CYL PIN NR 1.25X3.63USBX3.13CH
196-392H
65.
3S TORSION SPRING HANDLE RH
194-274D
66.
LOCK PLATE CASTER SWIVEL
402-511D
67.
SWIVEL LOCK PLATE YP24
402-516D
68.
HHCS 5/8-11X1 3/4 GR5
802-053C
69.
NET HEX 5/8-11 PLT
803-021C
70.
WASHER FLAT 1 1/4 SAE PLT
804-039C
71.
PIN ROLL 3/8 X 2 PLT
805-249C
72.
PIN 1 1/4X8.25 USBL HARD PLT
805-420C
73.
DECAL TRANSPORT LOCK ROAD
818-257C
74.
WASHER LOCK SPRING 5/8 PLT
804-022C
75.
401-406P
- 50 -
12/04/13
Gauge Wheels (continued)
(Applies to YP2425 only)
