Page 16
Revision
Comments
Part Description
Part No.
Ref.
WASHER LOCK SPRING 1/2 PLT
804-015C
49.
NUT HEX 1/2-13 PLT
803-020C
50.
MAIN AXLE REAR WELDMENT
402-242H
51.
AXLE LEVEL LINK YP24 WLDMT
401-694H
52.
PIN CLEVIS 1 1/4 X 6 7/8 USBL
805-312C
53.
PIN ROLL 1/4X1 3/4
805-041C
54.
HOSE CLIP 13/16 ID
800-064C
55.
HHCS 5/16-18X3 1/2 GR5 FTHD
802-190C
56.
PIN ROLL 3/8 X 2 1/2 PLT
805-255C
57.
BUSHING SPINDLE 1 1/2X1 1/4X1
890-011C
58.
PIN COTTER 7/32 X 2
805-060C
59.
WASHER FLAT 1 1/2 SAE PLT
804-071C
60.
U-BOLT 3/8-16 X 7 1/32 X 7 7/8
806-073C
61.
HOSE HOLD DOWN CLAMP
401-635D
62.
NUT LOCK 1/4-20 PLT
803-007C
63.
HOSE SUPPORT SHORT WELDMNT
403-234H
64.
HOSE SUPT SHORT RH WELDMT
403-243H
65.
HHCS 5/16-18X3/4 GR5
802-007C
66.
WASHER LOCK SPRING 5/16 PLT
804-009C
67.
SUPPORT, TOOLBAR AIR HOSE
403-381D
68.
CYL PIN NR 1.25X3.09X2.63 W/GR
196-409H
69.
Includes items 14, 52 & 71-72
LEVEL LINK ASM YP
401-693L
70.
NTA WING PIVOT SLEAVE
160-404D
71.
TURNBUCKLE SUB WELDMENT
566-042H
72.
401-406P
- 16 -
12/04/13
Mainframe (continued)
(Applies to YP2425 only)
