20
Section 2 Setup
Models ADI334 and ADI345 Air Drill Implement 160-243M 4/7/04
Great Plains Mfg., Inc.
Refer to Figure 2-18:
8.
Attach the end of the hose to opener.
Slide clamp over the end of the hose six inches. Put
the end of the hose in the seed tube six inches. Hook
the clamp ends in the holes at the top of the seed tube.
Figure 2-18
Hose Installation On Openers
14563
9. Repeat steps 1 through 8 for all one-inch hoses on each
tower.
10. When all hoses are installed on a tower, tighten the
bolts holding the halves together.
11. Check all hoses to be sure that they are not rubbing on
sharp edges and will not be damaged when the drill is
raised, lowered, folded or unfolded. Re-route if need-
ed to prevent damage.
IMPORTANT: The tower bolts are equipped with ny-
lock nuts and should not be over-tightened. Tighten
the bolts only until the hose is held securely against
being blown out.
