Page 10
8 TSF1080, TSF1090, TSF1280 and TSF1290
500-641Q
11/08/2006
Swivel Bolt Snap
Refer to Figure 2 and Figure 3
14. Unhook swivel bolt snap from stationary ring. Re-
hook swivel bolt snap to ring located in outer boom
lock plunger rod.
Figure 2
Swivel Bolt Snap (transport)
24164
Figure 3
Swivel Bolt Snap (operation)
24165
