43 Uni-Press
Operating Instructions
8. Parts & Assembly
AS0884 U N IPR ESS
AXLE COMPON EN T S
IT EM PART NO DESCRIPT ION 4.2 4.6 5.5 6.1 6.6 7.6 8.2 COMMENT S
1 P01619 BOLT U REF 06 M20 8 8 16 16 16 16 16
2 P06802 BOLT U REF 21 M16 14 14 15 17 19 22 27
3 P09558 SCRAPER - DD 600/700 16 17 21 23 25 29 33
4 P09559 SCRAPER STEM RH EXTND 6 7 7 8 9 11 13
5 P09560 SCRAPER STEM LH EXTND 7 7 7 8 9 11 13
6 P02008 NUT LOCK M16 TYPE 'T' 28 28 30 34 38 44 54
7 P02602 WASHER FLAT M16 28 28 30 34 38 44 54
8 P04179 WASHER FLAT M12 32 36 42 46 50 58 66
9 P02037 WASHER SPRING M12 32 36 42 46 50 58 66
10 P00003 BOLT M12x40 GR8.8 32 36 42 46 50 58 66
11 P02009 NUT LOCK M20 TYPE 'T' 16 16 32 32 32 32 32
12 P02603 WASHER FLAT M20 16 16 32 32 32 32 32
13 P10029 SCRAPER - DD600 HALF 2 2 2 2 2 2 2
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
