Uni-Press
Operating Instructions
8. Parts & Assembly
AS0886
U N IPR ESS 2000
LEVELLIN G BOAR D
IT EM
PART NO
DESCRIPTION
4.2 4.6 5.5 6.1 6.6 7.6 8.2
COMMENT S
1
P01619
BOLT U REF 06 M20
4
4
8
8
8 12 12
2
P09382
BOARD PIVOT Ø600 DD
4
4
6 6
6
8
8
3
P09384
LEVEL BOARD RAM POINT
2
2
2 2
2
2
2
4
P10718
LEVELLING BOARD LH 4.2m
1
5
P10717
LEVELLING BOARD RH 4.2m
1
6
P09386
LEVEL BOARD LH - 4.6m
1
7
P09385
LEVEL BOARD RH - 4.6m
1
8
P09388
LEVEL BOARD LH - 5.5m
1
9
P09387
LEVEL BOARD RH - 5.5m
1
10
P09390
LEVEL BOARD LH - 6.1m
1
11
P09389
LEVEL BOARD RH - 6.1m
1
12
P09392
LEVEL BOARD LH - 6.6m
1
13
P09391
LEVEL BOARD RH - 6.6m
1
14
P09394
LEVEL BOARD LH - 7.6m
1
15
P09393
LEVEL BOARD RH - 7.6m
1
16
P09396
LEVEL BOARD LH - 8.2m
1
17
P09395
LEVEL BOARD RH - 8.2m
1
18
P07834
SPRUNG LEAF
18
19
23 25
27
31
35
19
P05749
WEARPLATE
18
19
23 25
27
31
35
20
P09430
LEVEL BOARD RETAINER
8
8
12 12
12
16
16
21
P09431
PIVOT DISC
4
4
6
6
6
8
8
22
P10132
LEVEL BOARD STOP
4
4
4
4
4
4
4
23
P02603
WASHER FLAT M20
24 24 32 32 32 48 48
24
P02009
NUT LOCK M20 TYPE 'T'
16 16 24 24 24 24 24
25
P03087
BOLT M12x50 GR8.8
8
8
8
8
8
8
8
26
P02007
NUT LOCK M12 TYPE 'T'
8
8
8
8
8
8
8
27
P10991
CYL MOUNT
2
2
2
2
2
2
2
28
P10992
CYL MOUNT ADJUSTER
2
2
2
2
2
2
2
29
P02483
LYNCH PIN - CAT 1
8
8
8
8
8
8
8
30
P07743
PIN - Ø25x110
4
4
4
4
4
4
4
31
P00941
BOLT M30x90 GR8.8
2
2
2
2
2
2
2
32
P02011
NUT LOCK M30 TYPE 'T'
2
2
2
2
2
2
2
33
