6 Harrow Front Parts Great Plains Mfg., Inc.
116-156M Front Parts 2014-02-10
Part Lists
New Parts
116-162A Kit Contents
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Quantities are units (“ea”).
Existing Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Note: This part is factory pre-installed on all model
1205NT drills.
Call
-out
Part
Number
Description
116-162A 12’EWNT COIL TINE HARROW
21 116-154K 12’EWNT COIL TINE HARROW ASY
22 116-155K 12’HARROW ARM ASY
23 116-156M MANUAL 12’EWNT HARROW
24 813-009C 10 FT HARROW PALLET
116-154K 12’EWNT COIL TINE HARROW ASY
25 113-271D SHEAR BUSHING 5/8X.357
26 116-062H CENTER BRACE WELDMENT
27 116-064H 20’FRAME WELDMENT
28 116-189D HARROW TINE BAR
29 802-138C HHCS 5/16-18X2 1/4 GR5
30 803-084C NUT HEX NYLOCK 5/16-18 PLT
31 803-147C NUT HEX NYLOCK 1/2-13
32 804-010C WASHER FLAT 5/16 USS PLT
33 806-046C U-BOLT 1/2-13 X 1 3/8X2 3/4 LG
34 807-079C HARROW DBL TORSION SPRG 11 IN
116-155K 12’HARROW ARM ASY
35 116-129H HANGER ARM WELDMENT - 3PT
36 116-180D 3PT HANGER ARM CHAIN
37 802-022C HHCS 3/8-16X1 1/2 GR5
38 802-099C HHCS 1/2-13X3 1/4 GR5
39 803-014C NUT HEX 3/8-16 PLT
40 803-147C NUT HEX NYLOCK 1/2-13
41 804-011C WASHER FLAT 3/8 USS PLT
42 804-013C WASHER LOCK SPRING 3/8 PLT
43 806-046C U-BOLT 1/2-13 X 1 3/8X2 3/4 LG
Call
out
Part
Number
Part Description
11 151-027H HARROW ATTACHMENT WELDMENT
