American Sanders Operator's Manual - Sander 1600 120V
Page - 27 -
Ref. Part No. Description
Qty.
1
85383A Screw, 10-32 x
3
/
4
10
2
30285A Handle, Front
1
3
50798A Lever, Switch
2
4
50820A Spring, Extension
2
5
50806A Button, Interlock
1
6
40109A Switch
2
7
50799A Interlock, Main
1
8
50821A Spring, Compression
1
9
50780A Handle, Rear
1
10
920722 Nut, 10-32 ESNA
7
11
962957
Screw
2
13
10092A
Cord, Interconnect
1
14
461404
Cam, Locking (included in 55)
1
15
925592 Roll Pin, ¼ (included in 55)
1
16
441301 Bolt, Locking Cam (included in 55)
1
17
980349 Washer, Wear Cam
1
18
50791A Arm Link, RH
1
19
50781A Clamp, Handle
1
20
50792A Arm Link, LH
1
21
980645 Washer, Flat
3
/
8
1
22
920342 Nut,
3
/
8
-16 ESNA
2
23
87035A Washer, Fender #10 SS
2
24
50793A Wheel, 5"
2
25
87050A
Washer,
5
/
8
Nylon
2
26
50794A Bushing, Nylon
2
27
80087A Screw,
3
/
8
-16 x 6
1
28
57120A Plug, Button
1
29
40138A Motor, 1.5 HP
1
30
50979A
Gearbox
1
32
50985A
Frame, Main
1
33
50987A Shield, Brush
1
34
50782A Bumper
1
35
980652 Washer, Lock
5
/
16
4
36
85817A
Screw,
5
/
16
-18 x 2 (1600)
4
37
50796A
Bushing, Cord
1
38
50795A Tube, Handle
1
39
42207A Power Cord
1
40
50797A Relief, Strain (included w/41)
1
41
50991A
Cord Assembly (includes 40)
1
44
70499A Label
1
46
82100A
Lock nut (not illustrated)
1
53
962727
Screw, 8-32 x ½
2
55
441401
Cam Assembly (Incl. 14, 15, 16) (1)
56
41311A
Capacitor, Run
1
57
51523A
Bushing, Strain Relief
1
58
62667A
Cover, Enclosure
1
59
85833A
Screw, Ground
1
60
57165A
Plug, Nylon
1
61
170667
Wire Nut
2
Sander 1600
Assembly Drawing Parts List 2/03
Ref. Part No. Description
Qty.
62
77195A
Label, UL Fire
1
63
41312A Capacitor, Start
1
64
22906A Enclosure, Motor
1
65
962892 Screw, ¼-20 x
3
/
4
2
66
47409A
Switch, Start
1
68
73285A
Label, Warning
1
69
50930A Retainer, Cord
1
70
77234A Warning, Heavy
2
Part No.
Description
37007A
Pad Driver
460215
Sanding Plate
674117
1½" x 50' Bulk Hose
632418
1½" x Hose Cuffs (for above hoses)
682408
1½" Hose Coupler
639804
Wand Assembly
638820
Tool-Felt Shod. 14"
674114
Hose, Vac 1½' x 10'
634118
Hose, Vac 1½" x 15'
68805A
Weight, Machine
Optional Accessories Available
*
See Optional Accessories Table Above.
