AS2457 TINE FRAME LINK
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00053 BOLT M16x180 GR. 8.8 2
2 P02008 NUT LOCK M16 2
3 P02602 WASHER FLAT M16 4
4 P14385 SPLIT LINK - SHAFT 1
5 P14386 SPLIT LINK - PLAIN 1
