SL700
Operating Instructions
156
7. Parts and Assembly
157 SL700
Operating Instructions
7. Parts and Assembly
AS3542
ITEM PART NO DESCRIPTION QTY COMMENTS
1 H23410901 BOLT U M12 GR8.8 85x64 3
2 P00019 BOLT M24x120 GR. 8.8 1
3 P02007 NUT LOCK M12 6
4 P02008 NUT LOCK M16 'TYPE T' 2
5 P02010 NUT LOCK M24 1
6 P02483 LYNCH PIN CAT 1 1
7 P02601 WASHER FLAT M12 6
8 P02602 WASHER FLAT M16 2
9 P02604 WASHER FLAT M24 Ø50 2
10 P03704 BOLT U M16 GR8.8 145x117 1
11 P13744 PIN Ø16x108 1
12 P16599 HARROW MOUNTING 1
13 P16601 HARROW LIMIT STOP 1
14 P16610 HARROW ARM 1
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
FOLLOWING HARROW ARM ASSEMBLY
Parts
121 Simba SL700
603-216P
2013-01-25
